ZXMN3B01FTC Images
- Manufacturer: Diodes Inc. (Diodes)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23
- Description: MOSFET N-CH 30V 1.7A SOT23
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ZXMN3B01FTC Specifications:
- MfrPart.: ZXMN3B01FTC
- Mfr: Diodes Incorporated
- Description: MOSFET N-CH 30V 1.7A SOT23
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 1.7A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 150mOhm @ 1.7A, 4.5V
- Vgs(th)(Max)@Id: 0.7V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 2.93 nC @ 4.5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 258 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 625mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-23
- ZXMN3B01FTC Diodes Inc. (Diodes), MOSFET N-CH 30V 1.7A SOT23, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
ZXMN3B01FTC, Diodes authentic parts in stock from Diodes Inc. (Diodes) authorized distributors, order today, can ship immediately.
Diodes Inc. (Diodes) Authorized Distributor | NANHUANG is dedicated to providing first-quality, genuine Diodes components.
