DMN21D2UFB-7B Images
- Manufacturer: Diodes Inc. (Diodes)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 3-X1DFN1006
- Description: MOSFET N-CH 20V 760MA 3DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DMN21D2UFB-7B Specifications:
- MfrPart.: DMN21D2UFB-7B
- Mfr: Diodes Incorporated
- Description: MOSFET N-CH 20V 760MA 3DFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 760mA (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.5V, 4.5V
- RdsOn(Max)@IdVgs: 990mOhm @ 100mA, 4.5V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 0.93 nC @ 10 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 27.6 pF @ 16 V
- FETFeature: -
- PowerDissipation(Max): 380mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 3-X1DFN1006
- DMN21D2UFB-7B Diodes Inc. (Diodes), MOSFET N-CH 20V 760MA 3DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
