DMC1017UPD-13 Images
- Manufacturer: Diodes Inc. (Diodes)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-PowerTDFN
- Description: MOSFET N/P-CH 12V 9.5A/6.9A SMD
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DMC1017UPD-13 Specifications:
- MfrPart.: DMC1017UPD-13
- Mfr: Diodes Incorporated
- Description: MOSFET N/P-CH 12V 9.5A/6.9A SMD
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101
- PartStatus: Obsolete
- FETType: N and P-Channel Complementary
- FETFeature: Standard
- DraintoSourceVoltage(Vdss): 12V
- Current-ContinuousDrain(Id)@25°C: 13A (Ta), 9.4A (Ta)
- RdsOn(Max)@IdVgs: 17mOhm @ 11.8A, 4.5V, 32mOhm @ 8.9A, 4.5V
- Vgs(th)(Max)@Id: 1.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 18.6nC @ 4.5V, 23.7nC @ 4.5V
- InputCapacitance(Ciss)(Max)@Vds: 1787pF @ 6V, 2100pF @ 6V
- Power-Max: 2.3W
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-PowerTDFN
- DMC1017UPD-13 Diodes Inc. (Diodes), MOSFET N/P-CH 12V 9.5A/6.9A SMD, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
DMC1017UPD-13, Diodes authentic parts in stock from Diodes Inc. (Diodes) authorized distributors, order today, can ship immediately.
